1、Main characteristics
l Industrial design, adjust to high temperature and other bad environments;
l Simulated manpower friction card issuers ,better adaptability to various deformed cards;
l Watchdog of hardware and embedded operating system to ensure properly running;
l Pre-dispense function accelerate dispensing speed;
l Connectable with the vehicle detector to achieve card issuing and “one car, one card”;
l Automatic buzzer alarm when no cards, fewer cards or failure.
l Provide both RS232 and I/O voltage control interface;
l Automatic buzzer alarm when errors occur, automatic reset after 100 seconds alarm;
l Capacity of card stacker is more than 40pcs, automatic buzzer alarm when the withdrawing stacker is full;
l Slide card stacker with a capacity of 40pc;
l Adjustable of card stacker with a capacity of 120pc each;
l Automatic withdrawal to prevent card lost (only for TCD800F series
l Slide design to make installation and disassembling easier;
l Molded production to ensure high consistency of precision and quality.
2、Main technical data
l Operating voltage: 24VDC (max current 2A, static current 0.1A)
l Operating temperature: -20℃ to 85℃
l Operating humidity: 30-90% (comparatively)
l Use condition: install in bin
l Card available: width: 54+/-0.5mm
Length: 85+/-0.5mm
l Thickness: 0.3-2.5mm (adjustable)
l Card material: Paper or Polyester card
l Net weight of card dispenser: 2.0kg (including the briquette)
l Time of issuing: max0.5s
l Capacity of stacker: 150pcs (0.8mm), 100pcs available when an extra stacker is needed
